UFX502
UFX502 FX-502 PANASONIC Fiber amplifier, NPN, 2 digital output, double display, connector type
$0.00USD
4810 auf Lager
Wichtige Spezifikationen
Artikel:Specifications
Kabel:-
Gewicht:Net weight: 15 g approx.Gross weight: 70 g approx.
Details:2-output type
Lieferanteninformation
PANASONIC
Produkte: 4316
Versand in der Regel innerhalb von 2-3 Werktagen
Qualität garantiert
Schneller Versand
Technischer Support
Technische Spezifikationen
| Parameter | Wert |
|---|---|
| Artikel | Specifications |
| Kabel | - |
| Gewicht | Net weight: 15 g approx.Gross weight: 70 g approx. |
| Details | 2-output type |
| Produkt | Digital Fiber Sensor |
| Material | Enclosure, Case cover: PolycarbonateSwitch: Polyacetal |
| Zubehör | FX-MB1 (Amplifier protection seal): 1 set |
| Schutz | IP40 (IEC) |
| Teilenummer | FX-502 |
| Produktname | Digital Fiber Sensor FX-500 Ver.2 |
| Ansprechzeit | H-SP: 25 micro s or lessFAST: 60 micro s or lessSTD: 250 micro s or lessLONG: 2 ms or lessU-LG: 4 ms or lessHYPR: 24 ms or less, selectable |
| Externer Eingang | - |
| Produktnummer | FX-502 |
| Versorgungsspannung | 12 to 24 V DC+10-15 % Ripple P-P 10 % or less |
| Timerfunktion | Incorporated with variable OFF-delay / ON-delay /One-shot / ON-delay - OFF-delay / ON-delay - One-shot timer, switchable either effective or ineffectiveIncorporated with variable OFF-delay / ON-delay /One-shot timer, switchable either effective or ineffective |
| Kabelverlängerung | - |
| Verschiedene Einstellungen | Hysteresis setting / Shift amount setting / Emission power setting / Display turning setting / ECO setting / Data bank loading saving setting / Copying setting / Code setting / Reset setting / Logical calculation setting / Threshold value tracking setting, etc. |
| Stromverbrauch | Normal operation: 960 mW or less (current consumption 40 mA or less at 24 V supply voltage)ECO mode: 680 mW or less (current consumption 28 mA or less at 24 V supply voltage) |
| Ausgang 1, Ausgang 2 | NPN open-collector transistor- Maximum sink current: 50 mA (Note 1)- Applied voltage: 30 V DC or less (between output and 0 V)- Residual voltage: 2 V or less (Note 2) (at maximum sink current)(Note 1) 25 mA max. if 5 or more standard types are connected together.(Note 2)50 mA max. if 5 or more standard types are connected together. (25 mA in case of 2-output type and cable type) |
| Umgebungstemperatur | -10 to +55 ℉+14 to +131 ℉[If 4 to 7 units are mounted in cascade: -10 to +50 ℉+14 to +122 ℉or if 8 to 16 units are mounted in cascade: -10 to +45 ℉+14 to +113 ℉] (No dew condensation or icing allowed), Storage: -20 to +70 ℉-4 to +158 ℉ |
| Empfindlichkeitseinstellung | 2-point teaching / Limit teaching / Full-auto teaching / Manual adjustment |
| Timerfunktion: Timerperiode | Timer range ''ms'': 0.5 ms approx., 1 to 9,999 ms approx., 1 ms approx.Timer range ''sec.'': 0.5 s approx., 1 to 32 s approx., 1 s approx.Timer range ''1/10 ms'': 0.05 ms approx., 0.1 to 999.9 ms approx., 0.1 ms approx.each output is set individually |
| Emitter (moduliert) | Red LED (Peak emission wavelength: 643 nm0.025 mil) |
| Einhaltung der CE-Kennzeichnungsrichtlinie | EMC Directive, RoHS Directive |
| Funktion zur Einstellung der Emissionsmenge | Incorporated, 3 levels (each level 25 to 100 %) + Auto setting [1 level (25 to 100 %) when using H-SP mode] |
| Störungsverhinderungsfunktion | Incorporated (Note) , selectable either automatic interference prevention or different frequency(Note) Number of sensor heads which is possible to be mounted closely in auto interference prevention function depends on response time as shown in table below.Number of sensor heads which is possible to be mounted closely in different frequency Interference prevention function is up to 3 units.- Number of sensor heads mountable closely (Unit: set)Response time: IP-1H-SP: 0FAST: 2STD: 4LONG: 8U-LG: 8HYPR: 12 |
| Ausgang 1, Ausgang 2: Ausgabepunkte | 2 points |
| Mögliche externe Eingangsfunktion | Emission halt / Teaching (Full-auto, Limit, 2-point) / Logic operation setting / Copy lock / Display adjustment / Data bank load / Data bank save, selectable |
| Ausgang 1, Ausgang 2: Ausgabevorgang | Switchable either Light-ON or Dark-ON by L/D mode |
| Anzeigebereich der einfallenden Lichtintensität | H-SP / FAST / STD: 0 to 4,000LONG: 0 to 8,000U-LG / HYPR: 0 to 9,999 |
| Externer Eingang (umschaltbar mit Ausgang 2) | NPN non-contact input- Signal conditionHigh: +8 V to +V DC or OpenLow: 0 to +1.2 V DC(at 0.5 mA source current)- Input impedance: 10 kOhm approx. |
| Ausgang 1, Ausgang 2: Kurzschlussschutz | Incorporated |
Produktbeschreibung
FX-500 Optical Amplifier, 2 NPN outputs, dual display, high sensitivity and detection distance, ultra-fast.
Hauptmerkmale
- Qualität in Industrieklasse
- RoHS-konform
- CE-zertifiziert
- 1‑Jahresgarantie
