IDLC-45-350DA
IDLC-45-350DA MEANWELL AC-DC Constant Current LED Driver (CC), Output 95VDC / 0.35A, Dimming with DALI
$0.00USD
4966 auf Lager
Wichtige Spezifikationen
Name:IDLC-45-350DA
Zustand:New
Format:Box
Serie:IDLC-45-DA
Lieferanteninformation
MEANWELL
Produkte: 6448
Versand in der Regel innerhalb von 2-3 Werktagen
Qualität garantiert
Schneller Versand
Technischer Support
Technische Spezifikationen
| Parameter | Wert |
|---|---|
| Name | IDLC-45-350DA |
| Zustand | New |
| Format | Box |
| Serie | IDLC-45-DA |
| Dimmen | DALI |
| Genehmigungen | CCC, CE, ENEC, UL |
| Leistung (W) | 33,20 |
| Subformato | IP20 |
| Breite (mm) | 75.00 |
| Höhe (mm) | 25.00 |
| AC-Eingangsleistung Max. | 295,00 |
| Mindesteingangsleistung (AC): Mindestens | 90,00 |
| Anwendungen | Lighting |
| Hersteller | MEAN WELL |
| Produktart | LED Driver |
| Isolation (V) | 3.750,00 |
| Spitzenleistung (W) | 33.2 |
| Eingangsanschluss | Quick Connector |
| Eingangsfrequenz | 50 Hz, 60 Hz |
| Lang/Hintergrund | 120.00 |
| Lange Beschreibung | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format in plastic boxIP20.Input range90-295Vca47-63Hz.Output in constant current350mA.Range of output voltage with current mode constant57 to 95Vccaccording to demand load.Power:To 33.2 W.Efficiency typical:86%.Regulation DALI0% to 100% of the output intensity. Certificate to DALI.Input class II without grounding.Factor corrector, power>0.92to 230vac at full load.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-20ºCup+85ºC.Dimensions (Length x Width x Height):120 x 75 x 25mm.3 years of warranty.Manufacturer: MEAN WELL.The series IDLC are LED drivers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream. With plastic housing designed for lighting applications in interior. Low ripple current, no flicker (flicker-free).This source works on a Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.Compatible with any system DALI. |
| Ausgangsanschluss | Quick Connector |
| Art des Eintrags CA | Single-phase |
| Garantie (Jahre) | 3,00 |
| Ursprungsland | China |
| Ausgangsstrom mA | Three hundred fifty |
| Intensität der minimalen Ausgangsleistung (mA) | 350,00 |
| Maximale Ausgangsintensität (mA) | 350,00 |
Produktbeschreibung
More details
Hauptmerkmale
- Qualität in Industrieklasse
- RoHS-konform
- CE-zertifiziert
- 1‑Jahresgarantie
Technische Details
LED driver dimmable.
Produktdokumente
Datenblatt
Technische Spezifikationen und Leistungsdaten
Benutzerhandbuch
Installations- und Betriebsanleitung
