HLG-80H-54
HLG-80H-54 MEANWELL AC-DC Single output LED driver Mix mode (CV+CC) with built-in PFC, Output 54VDC / 1.5A, ..
$0.00USD
3070 auf Lager
Wichtige Spezifikationen
Name:HLG-80H-54
Zustand:Recommended Model
Format:Box
Serie:HLG-80H
Lieferanteninformation
MEANWELL
Produkte: 6448
Versand in der Regel innerhalb von 2-3 Werktagen
Qualität garantiert
Schneller Versand
Technischer Support
Technische Spezifikationen
| Parameter | Wert |
|---|---|
| Name | HLG-80H-54 |
| Zustand | Recommended Model |
| Format | Box |
| Serie | HLG-80H |
| Genehmigungen | CCC, CE, EAC, KCC, MM, PSE, RCM, TUV, UL |
| Leistung (W) | 81,00 |
| Subformato | IP67 |
| Breite (mm) | 61.50 |
| Höhe (mm) | 38.80 |
| AC-Eingangsleistung Max. | 305,00 |
| Mindesteingangsleistung (AC): Mindestens | 90,00 |
| Anwendungen | Lighting |
| Hersteller | MEAN WELL |
| Produktart | LED Driver |
| Isolation (V) | 3.750,00 |
| Spitzenleistung (W) | Eighty one |
| Eingangsanschluss | Cable |
| Eingangsfrequenz | 50 Hz, 60 Hz |
| Lang/Hintergrund | 195.60 |
| Lange Beschreibung | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range90-305Vca47-63Hz.Output in constant current1500mA.Range of output voltage with current mode constant32,4 to 54Vccaccording to demand load.Power:81W.Efficiency typical:91%.Input class I with grounding.Factor corrector, power>0.96to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+70ºC.Dimensions (Length x Width x Height):195,6 x 61,5 x 38,8 mm7 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.The series HLG are LED drivers, class I grounded.You can also work in voltage mode constant giving a fixed voltage of 54V if the load is powered at constant voltage and does not overcome the maximum output power.With metal housing, waterproof to IP67. The series HLG has a high efficiency designed for applications of public lighting, architectural, exterior, interior or any lighting application LED needs a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. Suitable for LED lighting or LED displays. Complies with the requirements of security at the global level for lighting. |
| Ausgangsanschluss | Cable |
| Art des Eintrags CA | Single-phase |
| Garantie (Jahre) | 7,00 |
| Ursprungsland | China |
| Ausgangsstrom mA | One thousand five hundred |
| Intensität der minimalen Ausgangsleistung (mA) | 1.500,00 |
| Maximale Ausgangsintensität (mA) | 1.500,00 |
Produktbeschreibung
More details
Hauptmerkmale
- Qualität in Industrieklasse
- RoHS-konform
- CE-zertifiziert
- 1‑Jahresgarantie
Technische Details
LED driver.
Produktdokumente
Datenblatt
Technische Spezifikationen und Leistungsdaten
Benutzerhandbuch
Installations- und Betriebsanleitung
