ELN-60-24
ELN-60-24 MEANWELL AC-DC Single output LED driver Mix mode (CV+CC), Output 24VDC / 2.5A
$0.00USD
4631 auf Lager
Wichtige Spezifikationen
Name:ELN-60-24
Zustand:Do not Use for New Designs
Aktie:Yes
Format:Box
Lieferanteninformation
MEANWELL
Produkte: 6448
Versand in der Regel innerhalb von 2-3 Werktagen
Qualität garantiert
Schneller Versand
Technischer Support
Technische Spezifikationen
| Parameter | Wert |
|---|---|
| Name | ELN-60-24 |
| Zustand | Do not Use for New Designs |
| Aktie | Yes |
| Format | Box |
| Serie | ELN-60 |
| Genehmigungen | CE, UL |
| Leistung (W) | 60,00 |
| Subformato | IP64 |
| Breite (mm) | 61.50 |
| Höhe (mm) | 35.00 |
| AC-Eingangsleistung Max. | 264,00 |
| Mindesteingangsleistung (AC): Mindestens | 90,00 |
| Anwendungen | Industrial, Telecommunications |
| Hersteller | MEAN WELL |
| Produktart | LED Driver |
| Isolation (V) | 3.000,00 |
| Ausgangsspannung | 24,00 |
| Spitzenleistung (W) | Sixty |
| Eingangsanschluss | Cable |
| Eingangsfrequenz | 50 Hz, 60 Hz |
| Lang/Hintergrund | 181.00 |
| Lange Beschreibung | LED driver.Specially designed to feed LED strips.Format in plastic boxIP64.Input range90-264vac47-63Hz.Output voltage24vdc.Adjustable by internal potentiometer SVR1 (21,6-26,4 Vdc).Output intensity2.5 To. Range of output current 0-2,5 a according To demand load.Maximum output current adjustable via potentiometer internal to SVR2 (-25% to +3%).Power:60W.Efficiency typical:87%.Potentiometers:This model incorporates 2 potentiometers inside that allows us to regulate the output voltage and the maximum output current.Input class II without grounding.Operating temperature range of caseTcfrom-20ºCup+60ºC.Dimensions (Length x Width x Height):181 x 61.5 x 35mm.2 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with LED strips or LED bulbs, which are fed at constant voltage. Trabaja-mode voltage constant by giving a fixed voltage of 24V if the load is powered at constant voltage and does not overcome the maximum output power. The output voltage and the output current can be adjusted byknobs internal(SVR1 / SVR-2), located in the plate of the source.With plastic housing, designed for applications of LED-lighting and signalling mobile. Suitable for interior lighting and electronic displays. |
| Ausgangsanschluss | Cable |
| Art des Eintrags CA | Single-phase |
| Garantie (Jahre) | 2,00 |
| Ursprungsland | China |
Produktbeschreibung
More details
Hauptmerkmale
- Qualität in Industrieklasse
- RoHS-konform
- CE-zertifiziert
- 1‑Jahresgarantie
Technische Details
LED driver.
