CLG-150-48
CLG-150-48 MEANWELL AC-DC Single output LED driver Mix mode (CV+CC) with PFC, Output 48VDC / 3A, IP67, cable..
$0.00USD
4175 auf Lager
Wichtige Spezifikationen
Name:CLG-150-48
Zustand:Do not Use for New Designs
Format:Box
Serie:CLG-150
Lieferanteninformation
MEANWELL
Produkte: 6448
Versand in der Regel innerhalb von 2-3 Werktagen
Qualität garantiert
Schneller Versand
Technischer Support
Technische Spezifikationen
| Parameter | Wert |
|---|---|
| Name | CLG-150-48 |
| Zustand | Do not Use for New Designs |
| Format | Box |
| Serie | CLG-150 |
| Genehmigungen | CCC, CE, PSE, UL |
| Leistung (W) | 153,60 |
| Subformato | IP67 |
| Breite (mm) | 68.00 |
| Höhe (mm) | 38.80 |
| AC-Eingangsleistung Max. | 295,00 |
| Mindesteingangsleistung (AC): Mindestens | 90,00 |
| Anwendungen | Lighting |
| Hersteller | MEAN WELL |
| Produktart | LED Driver |
| Isolation (V) | 3.750,00 |
| Spitzenleistung (W) | 153.6 |
| Eingangsanschluss | Cable |
| Eingangsfrequenz | 50 Hz, 60 Hz |
| Lang/Hintergrund | 222.20 |
| Lange Beschreibung | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range90-295Vca47-63Hz.Output in constant current3.2 A.Range of output voltage with current mode constant36 to 48vdcaccording to demand load.Power:153,6 W.Efficiency typical:Ninety one%.Input class I with grounding.Factor corrector, power>0.95to 230vac at full load.Operating temperature range of caseTcfrom-30ºCup+70ºC.Dimensions (Length x Width x Height):222,2 x 68 x 38,8 mm3 years of warranty.Manufacturer: MEAN WELL.The series CLG are LED Drvers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.You can also work in voltage mode constant giving a fixed voltage of 48V if the load is powered at constant voltage and does not overcome the maximum output power.With metal housing water-tight. The series CLG has a high reliability with active PFC. Burn test at 100% load. Suitable for applications of LED lighting, signage, mobile, and public lighting in dry environments, humid, and wet conditions . Complies with the requirements of security at the global level for lighting.Include cable approved for Europe (VDE) , Usa (UL), Korea (KC), Taiwan (BSMI) , China (CCC), Brazil (IEC 60245-4 ), Australia (RCM) and Japan (PSE). |
| Ausgangsanschluss | Cable |
| Art des Eintrags CA | Single-phase |
| Garantie (Jahre) | 3,00 |
| Ursprungsland | China |
| Ausgangsstrom mA | Three thousand two hundred |
| Intensität der minimalen Ausgangsleistung (mA) | 3.200,00 |
| Maximale Ausgangsintensität (mA) | 3.200,00 |
Produktbeschreibung
More details
Hauptmerkmale
- Qualität in Industrieklasse
- RoHS-konform
- CE-zertifiziert
- 1‑Jahresgarantie
Technische Details
LED driver.
Produktdokumente
Datenblatt
Technische Spezifikationen und Leistungsdaten
Benutzerhandbuch
Installations- und Betriebsanleitung
