Vorrätig Top‑Produkt
CEN-75-20
CEN-75-20 MEANWELL AC-DC Single output LED driver Mix mode (CV+CC), Output 20VDC / 3.75A
$0.00USD
3266 auf Lager
Wichtige Spezifikationen
Name:CEN-75-20
Zustand:Do not Use for New Designs
Format:Box
Serie:CEN-75
Lieferanteninformation
MEANWELL
Produkte: 6448
Versand in der Regel innerhalb von 2-3 Werktagen
Qualität garantiert
Schneller Versand
Technischer Support
Technische Spezifikationen
| Parameter | Wert |
|---|---|
| Name | CEN-75-20 |
| Zustand | Do not Use for New Designs |
| Format | Box |
| Serie | CEN-75 |
| Genehmigungen | CE, PSE, UL |
| Leistung (W) | 75,00 |
| Subformato | IP66 |
| Breite (mm) | 62.50 |
| Höhe (mm) | 40.50 |
| AC-Eingangsleistung Max. | 295,00 |
| Mindesteingangsleistung (AC): Mindestens | 90,00 |
| Anwendungen | Lighting |
| Hersteller | MEAN WELL |
| Produktart | LED Driver |
| Isolation (V) | 3.750,00 |
| Spitzenleistung (W) | Seventy five |
| Eingangsanschluss | Cable |
| Eingangsfrequenz | 50 Hz, 60 Hz |
| Lang/Hintergrund | 185.00 |
| Lange Beschreibung | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in metal boxIP66.Input range90-295Vca47-63Hz.Output in constant current3,75 A.Adjustable by external potentiometer (2,81-3,75).Range of output voltage with current mode constant15 to 20vdcaccording to demand load.Output voltage with current mode constant20vdc.Adjustable by external potentiometer (17-22Vcc).Power:75W.Efficiency typical:88%.Potentiometers:This model incorporates 2 external potentiometers that allows us to regulate the output voltage and the maximum output current.Input class I with grounding.Factor corrector, power>0.95to 230vac at full load.Operating temperature range of caseTcfrom-30ºCup+70ºC.Dimensions (Length x Width x Height):185 x 62,5 x 40,5 mm3 years of warranty.Manufacturer: MEAN WELL.The series CEN are LED Drvers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source can operate in either Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current. The output voltage and the output current can be adjusted byexternal potentiometerslocated in the housing of the source.With metal housing, suitable for LED lighting and signalling mobile in dry environments, humid, and wet conditions. Valid for interior and exterior. This model has a noise and ripple maximum of 2.4 Vp-p, so that should not be used with controllers, just to feed directly into LEDs. Complies with the requirements of security at the global level for lighting. Test burn at 100% load. High reliability with PFC (correction Factor for Power) is active. |
| Ausgangsanschluss | Cable |
| Art des Eintrags CA | Single-phase |
| Garantie (Jahre) | 3,00 |
| Ursprungsland | China |
| Ausgangsstrom mA | 3500, 4000 |
| Intensität der minimalen Ausgangsleistung (mA) | 3.750,00 |
| Maximale Ausgangsintensität (mA) | 3.750,00 |
Produktbeschreibung
More details
Hauptmerkmale
- Qualität in Industrieklasse
- RoHS-konform
- CE-zertifiziert
- 1‑Jahresgarantie
Technische Details
LED driver.
Produktdokumente
Datenblatt
Technische Spezifikationen und Leistungsdaten
Benutzerhandbuch
Installations- und Betriebsanleitung
